Why choose code 5 240mm 6m roofing lead?

The code 5 240mm 6m roofing lead roll offers a powerful combination of strength, durability and versatility. At 240mm wide, it sits at the boundary between narrow flashings and mid-width weatherings, making it suitable for a broad range of detailing where a heavier gauge is essential. The increased thickness of Code 5 (approx. 2.24mm) ensures long-term performance on exposed roof elevations and heritage projects.

As a BS EN 12588 certified rolled sheet, the code 5 240mm 6m roofing lead provides a uniform metallurgical structure and predictable forming behaviour. Installers value this size for stepped flashings, apron flashings, deep soakers and junction weatherings where structural reliability and long service life are key deliverables.

The extended 6m roll length reduces the number of joints required, offering both visual and waterproofing advantages. Longer lengths help create uninterrupted runs of weathering, while still allowing installers to cut bays to appropriate lengths for Code 5 movement characteristics.

For accurate roll weights, coverage and bay sizing, use our
Lead Flashing & Lead Roll Calculator.

Typical uses for code 5 240mm 6m roofing lead

This mid-width Code 5 specification is ideal for:

• Chimney apron flashings and stepped flashings.
• Deep soakers beneath slate or tile installations.
• Cover flashings to pitched and flat roof intersections.
• Weatherings on dormer cheek flashings and window heads.
• Strength-critical flashings in high-wind or coastal regions.
• Conservation-grade repairs on traditional and heritage buildings.

Why Code 5 is preferred for demanding weathering details

Medium-width flashings like code 5 240mm 6m roofing lead are regularly exposed to significant thermal and mechanical stress. Code 5’s increased thickness provides:

• Superior resistance to fatigue cracking.
• Greater rigidity for long-term performance on exposed details.
• Excellent shaping without overstretching.
• Suitability for both modern and heritage roofing applications.

For architects and surveyors specifying materials, Code 5 is often the minimum gauge acceptable for structural weatherings, making the 240mm width a frequently used option across restoration and high-performance builds.

Installation guidance

Install code 5 240mm 6m roofing lead following BS EN 12588 workmanship principles and LSTA/LSA best practice. Thermal movement allowance is crucial when installing any Code 5 gauge sheet, especially when used for long runs of flashings.

After fixing, apply patination oil to stabilise early-weathering behaviour and prevent carbonate staining, ensuring a clean and consistent finish.

For sealing chases or masonry penetrations, use traditional mortar bedding or
Lead Mate Sealant
for flexible finishing.

Installation essentials

1. Prepare the chase: Uniform, clean and capable of holding the lead securely.
2. Cut lengths appropriately: Keep to recommended bay sizing for Code 5 movement limits.
3. Fix with correct materials: Use copper or stainless fasteners from our
   Leadwork Fixings range.
4. Seal joints and chases: Use mortar or Lead Mate depending on detail and substrate.
5. Finish and protect: Apply patination oil to all exposed surfaces immediately.

Further reading & trusted guidance

For more detail on Code 5 applications, explore
The Lead Handbook,
longstanding trade resources at
The Lead Lads,
and professional leadwork services by
Neal Roofing.

Recommended accessories

For optimal performance, pair code 5 240mm 6m roofing lead with:
Lead Underlay,
Patination Oil,
Lead Mate Sealant,
and durable fixings from our
Leadwork Fixings range.

At a glance — code 5 240mm 6m roofing lead

Figures are approximate. Always install to BS EN 12588 and LSTA/LSA detailing guidance.
